Slot Cutters

Slot Cutters

Slot Cutters
Tongues and grooves are easy to make with these versatile slot cutter assemblies. It is very useful to be able to assemble these cutting heads, as opposed to buying solid heads. You can then mix and match the cutting heads, spacers, and ring bearings, on the arbor to create the profile of the edge or joint you need.

When you are working freehand with fence or with a router table you need only the slot cutter arbor and the right thickness of slot cutter, or 2 slot cutters, if you want to cut two grooves at the same time. The arbor comes with a set of depth control rings that work well for most applications. For special needs, for instance when you want to mount two slot cutters with a defined and precise distance between them, you can also use the spacers we offer in from 0.1 mm to 6 mm diameter.

A ring bearing can be used to adjust the depth of cut when you would like to use the edge of the wood to guide the tool in the various configurations. We offer various widths of ring bearings so that one can be flexible in the disposition of the various elements to work as consistently and cleanly as possible. The ring bearings can be mounted over or under the cutting heads. Or it is possible to use two slot cutting heads with the ring bearing mounted in between them.

These Sistemi Klein router bits are Tungsten Carbide tipped (TCT).

Slot Cutter Arbor

Dia-
meter
D
For
Slot cutters
with hole Ø
d
Shank
diameter
S
Spacers
included
Total
length
L
CodePrice
16 mm 8 mm 8 mm 2 x 1 mm
1 x 3 mm
3 x 6 mm
70 mm
Code 360610CartPrice € 10.50
Slot Cutters
Teeth width

Slot Cutters

Cutting
width
B
Dia-
meter
D
Diameter
of inner hole
d
Material CodePrice
1.6 mm 47.6 mm 8 mm TCT
Code 360750CartPrice € 15.50
2 mm 47.6 mm 8 mm TCT
Code 360751CartPrice € 15.50
2.4 mm 47.6 mm 8 mm TCT
Code 360752CartPrice € 15.90
3 mm 47.6 mm 8 mm TCT
Code 360753CartPrice € 15.90
3.2 mm 47.6 mm 8 mm TCT
Code 360754CartPrice € 16.50
4 mm 47.6 mm 8 mm TCT
Code 360755CartPrice € 16.50
4.8 mm 47.6 mm 8 mm TCT
Code 360756CartPrice € 16.70
Cutting width Diameter D Diameter d Material CodePrice
5 mm 47.6 mm 8 mm TCT
Code 360757CartPrice € 16.70
6 mm 47.6 mm 8 mm TCT
Code 360758CartPrice € 16.70
6.4 mm 47.6 mm 8 mm TCT
Code 360759CartPrice € 16.70

Ball Bearings

Dia-
meter
D
Diameter
of inner hole
d
Thickness
B
CodePrice
19 mm 8 mm 6 mm
Code 362010CartPrice € 1.75
22 mm 8 mm 7 mm
Code 362011CartPrice € 1.75
24 mm 8 mm 8 mm
Code 362012CartPrice € 1.75
28 mm 8 mm 9 mm
Code 360633CartPrice € 6.20
33.5 mm 8 mm 8.6 mm
Code 360634CartPrice € 10.50
Spacers

Spacers

Dia-
meter
D
Diameter
of inner hole
d
Thickness
B
CodePrice
16 mm 8 mm 0.1 mm
Code 360773CartPrice € 1.05
16 mm 8 mm 0.5 mm
Code 360772CartPrice € 1.05
16 mm 8 mm 1 mm
Code 360771CartPrice € 1.25
16 mm 8 mm 3 mm
Code 360774CartPrice € 1.30
16 mm 8 mm 6 mm
Code 360775CartPrice € 1.30
