Juuma Block Planes

Juuma Block Planes

JUUMA Block Plane The plane's body is made of stress-relieved gray cast iron. The 3 mm thick high carbon steel blade is hardened to 61 - 63 HRC. With the introduction of this plane we trust to have closed the large gap between the cheap planes and the premium planes. This plane is the missing link regarding quality and price.
With blade adjustment
With mouth adjustment
Weight 830 g
Total length 163 mm (6-1/2 inch)
Plane body width 44 mm (1-3/4 inch)
Blade width 35 mm (1-3/8 inch)
Blade thickness 3 mm (1/8 inch)
Blade hardness 61 - 63 HRC
Cutting angle 45° (Iron bedded at 20°)
Result of hardness test
All JUUMA planes
Manual (PDF 1.3 MB) print out just here
Code 300030CartPrice € 67.00

Repl. Blade for Juuma Block Plane
Code 300031CartPrice € 11.50
JUUMA Low Angle Block Plane The body of this low angle block plane is made of stress-relieved gray cast iron. The 3 mm thick high carbon steel blade is hardened to 61 - 63 HRC. With the introduction of this plane we trust to have closed the large gap between the cheap planes and the premium planes. This plane is the missing link regarding quality and price.
with blade adjustment
with mouth adjustment
Weight 770 g
Total length 163 mm (6-1/2 inch)
Plane body width 44 mm (1-3/4 inch)
Blade width 35 mm (1-3/8 inch)
Blade thickness 3 mm (1/8 inch)
Blade hardness 61 - 63 HRC
Cutting angle 38° (Iron bedded at 13°)
All JUUMA Planes
Manual (PDF 1.3 MB) print out just here
Code 300050CartPrice € 75.00

Repl. Blade for JUUMA Low Angle Block Plane
Code 300051CartPrice € 11.50
