JUUMA Smoothing Planes

JUUMA Smoothing Planes

JUUMA Smoothing Plane no. 4 The plane's body is made of stress-relieved gray cast iron. The frog is made of brass. The 3 mm thick high carbon steel blade is hardened to 61 - 63 HRC and connected with a thick and stable chipbreaker. The handles are made of Cherrywood. With the introduction of this plane we trust to have closed the large gap between the cheap planes and the premium planes. This plane is the missing link regarding quality and price.
Total length 250 mm (10 inch)
Width of body 62 mm (2-7/16 inch)
Blade width 50.8 mm (2 inch)
Blade thickness 3.2 mm (1/8 inch)
Blade hardness 61 - 63 HRC
Chipbreaker thickness 3 mm (1/8 inch)
Iron bedded at 45°
Weight 2200 g (4-1/2 lb)
All Juuma Planes
Result of hardness test
Instructions (PDF)
Code 300034CartPrice € 159.00

Repl. Blade for Juuma Smoothing Plane No. 4
Blade width 50.8 mm (2 inch)
Blade thickness 3.2 mm (1/8 inch)
Fits also many but not all common No 4 planes. You can easily check this by yourself by underlaying a piece of carton or veneer with a thickness 3.2 mm minus the thickness of your existing blade.
Code 300035CartPrice € 13.50
