Depth Stops

Depth Stops

Set of Depth Collars
Made by FAMAG, Germany
includes one each: 3, 4, 5, 6, 8, 10, 12 mm
to slip onto the drill bit.
Info: lock the screw thoroughly.
Code 304710CartPrice € 10.20
Depth Stops
Depth Stops

Depth Stops
Depth Stops
Depth Stops
Depth Stops
These depth stops feature a special plastic cap which rotates with the depth stop. When the cap comes in contact with the workpiece, it stops rotating, which indicates that the desired depth has been reached; it also prevents the depth stop from making ugly friction marks on the work. Notches in the caps allow chips to escape. Drill bit shown is not included!
Video - in Japanese language with English subtitles!
Video - in Japanese language without subtitles!
Enlargement and Instructions

Drill Diameter Height A Width B CodePrice
3 mm 25 mm 22 mm
Code 312603CartPrice € 6.25
4 mm 25 mm 22 mm
Code 312604CartPrice € 6.25
5 mm 25 mm 22 mm
Code 312605CartPrice € 6.25
6 mm 25 mm 22 mm
Code 312606CartPrice € 6.25
8 mm 28 mm 26 mm
Code 312608CartPrice € 7.25
9 mm 28 mm 26 mm
Code 312609CartPrice € 7.25
10 mm 25 mm 22 mm
Code 312610CartPrice € 7.45
Diameter Height Width CodePrice
11 mm 31 mm 30 mm
Code 312611CartPrice € 8.90
12 mm 31 mm 30 mm
Code 312612CartPrice € 8.90
13 mm 41 mm 38 mm
Code 312613CartPrice € 10.90
15 mm 41 mm 38 mm
Code 312615CartPrice € 10.90
16 mm 43 mm 46 mm
Code 312616CartPrice € 11.25
18 mm 43 mm 46 mm
Code 312618CartPrice € 11.50
24 mm 54 mm 57 mm
Code 312619CartPrice € 13.90
Diameter Height Width CodePrice
27 mm 63 mm 63 mm
Code 312600CartPrice € 17.90
30 mm 68 mm 68 mm
Code 312601CartPrice € 17.90

Example how to use

  1. Drilling with mounted drill stopper.
  2. Drill stopper stops rotating when bit reaches the adjusted depth.
  3. Clean hole, no scratches on the surface!
