Combination Squares

Combination Squares

We have offered combination squares in the past, but due to their generally poor quality, we stopped stocking them, and have not carried them for quite a while.

Now we are happy to be able to offer the world’s best. It is made by STARRETT, in Athol, Massachusetts, USA. In the December, 2002 issue of Fine Woodworking, many combination squares were tested and reviewed. Of its type, the STARRETT was deemed to be "the best tool on the market", and the brand has long been thought to be the "gold standard" when it comes to squares and rules.

The hardened and tempered steel ruler is machine marked. The graduations are deeply etched and easy to read. On one side of the ruler, the graduations in 1 mm and 1/2 mm run from left to right, and on the other the same scale runs from right to left. It comes with regular finish.

STARRETT offers the square head and centred head made of cast iron or of forged and hardened steel. Our regular package features the quality option: forged and hardened steel, so you get the best available. The round protractor head is made of cast iron and is reversible.

Very useful accessories included in the package are the the hardened-steel scriber and the spirit levels included in the square and protractor heads.

We also offer an economy-grade combination square. This is a relatively inexpensive square, but one that you can trust, as with all other STARRETT tools. The blade is only 150 mm long, the fence is made of cast iron, and the scriber and spirit level are not included.

Click pictures for magnified views!

Take the time to also have a look at the STARRETT Double Squares and the STARRETT steel rules!

Video
STARRETT Combination Square
with one head: square head 90°/45°
Forged and hardened steel
Handy spirit level and hardened scriber included
Blade 300 x 25 x 2.4 mm
Detail view head
Detail view scale
Graduations:
1. side: mm und 1/2 mm from left to right
2. side: mm und 1/2 mm from right to left
Blade Regular Finish
STARRETT code 33MH-300
Code 306420CartPrice € 109.00

Combination Square as above, but
Blade Satin Chrome Finish
Blade 300 x 25 x 2.4 mm
STARRETT code C33MH-300
Currently not in stock!
Code 306385Cart
Price € 135.00

Combination Square as above, but
INCH graduation - blade 12 inch long
Blade Regular Finish
Blade 12 x 1 x 3/32 inch
STARRETT code 33H-12-4R
Currently not in stock!
Code 306416Cart
Price € 89.00

Combination Square as above, but
Short type with blade 150 mm
Blade Regular Finish
Blade 150 x 19 x 2 mm
STARRETT code 33MH-150
Currently not in stock!
Code 306418Cart
Price € 89.00

Combination Square as above, but
Short type with blade 150 mm
Blade Satin Chrome Finish
Blade 150 x 19 x 2 mm
STARRETT code C33MH-150
Code 306383CartPrice € 105.00
STARRETT Combination Square
with two heads:
1. square head 90°/45°
2. center head
Forged and hardened steel
Handy spirit level and hardened scriber included
Blade 300 x 25 x 2.4 mm
Graduations:
1. side: mm und 1/2 mm from left to right
2. side: mm und 1/2 mm from right to left
Regular Finish
STARRETT code 33MHC-300
Code 306421CartPrice € 159.00

Combination Square as above, but
Blade Satin Chrome Finish
Blade 300 x 25 x 2.4 mm
STARRETT code C33MHC-300
Code 306386CartPrice € 189.00
STARRETT Combination Square
with three heads:
1. square head 90°/45°
2. center head
3. protractor head
Forged and hardened steel (except center head)
Handy spirit level and hardened scriber included
Blade 300 x 25 x 2.4 mm
Graduations:
1. side: mm und 1/2 mm from left to right
2. side: mm und 1/2 mm from right to left
Regular Finish
STARRETT code 434M-300
Code 306422CartPrice € 249.00

Combination Square as above, but
Blade Satin Chrome Finish
Blade 300 x 25 x 2.4 mm
STARRETT code C434M-300
Currently not in stock!
Code 306387Cart
Price € 269.00
Square Head
Square Head 90°/45° for Starrett Combination Squares with Blade 300 or 600 mm
not suitable for blades 150 mm long
Forged and hardened steel!
STARRETT code H33-1224
Code 306404CartPrice € 71.50
Center Head
Center Head for Starrett Combination Squares with Blade 300 or 600 mm
not suitable for blades 150 mm long
Forged and hardened steel!
STARRETT code C33-1224
Code 306405CartPrice € 55.00
Protractor Head for Starrett Combination Squares with Blade 300 or 600 mm
not suitable for blades 150 mm long
with spirit level on back side
Ideal addition when you own an Starrett combination square without this head
STARRETT code PR-1224S
Code 306407CartPrice € 89.00
Repl. Steel Blade for Starrett Combination Squares
Graduations:
1. side: mm und 1/2 mm from left to right
2. side: mm und 1/2 mm from right to left
Cross section 25 x 2.4 mm

Steel Blade 300 mm long
Regular Finish
STARRETT code B300-35
Code 306406CartPrice € 43.90

Steel Blade 300 mm long
Satin Chrome Finish
STARRETT code CB300-35
Code 306391CartPrice € 67.00

Steel Blade 600 mm long
Regular Finish
STARRETT code B600-35
Code 306408CartPrice € 99.00

Steel Blade 600 mm long
Satin Chrome Finish
STARRETT code CB600-35
Currently not in stock!
Code 306392Cart
Price € 117.00
STARRETT Combination Square Economy grade
with one head: square head 90°/45°
Head made of cast iron
Level and scriber NOT included
Blade 150 x 19 x 2 mm
Graduations:
1. side: mm und 1/2 mm from left to right
2. side: mm und 1/2 mm from right to left
Regular Finish
STARRETT code 10MH-150
Currently not in stock!
Code 306425Cart
Price € 59.90
