One Handed Quick Action Bar Clamp EHZ-30-2K Opening
300 mm BESSEY
Available, delivery time: 1-3 businessdays within Germany
Product information
With these one-handed clamps featuring an all-steel rail, a significantly higher clamping force is achieved than with the previously described one-handed clamps with a plastic head. The grip can be held with one hand while simultaneously operating the pump lever. This is particularly important when you need to hold the workpiece parts with the other hand. Additionally, the pump lever can be operated even when one hand holds the clamp from the rail side and the grip is not involved at all. The quick-release button allows for easy movement of the grip unit. The removable protective caps are soft and have a smooth and adhesive surface for gentle clamping. Easy switching from clamping to spreading makes the EHZ a versatile clamping tool. The ergonomic handle is made from 2-component plastic.
- Clamping force up to 3500 N
- Easy and quick fixing and clamping with just one hand
- Pump lever operable from rail and grip side
- With protective caps on the clamping surfaces
| Features | |
|---|---|
| Weight | 1250 g |
| Manufacturer No. | EHZ30-2K |
| Rail | 19.5 × 9.5 mm |
| Clamping depth | 100 mm |
| Clamping width | 300 mm |
