Alu-Line plane without engraving
240 x 115 x 60 mm ULMIA

10% Discount
Alu-Line plane without engraving 240 x 115 x 60 mm ULMIA
€167.31* €185.90*
You save €18.59!

Prices incl. VAT plus shipping costs

Available, delivery time: 1-3 businessdays within Germany

Design
Product number: 300470

Product information

Massive anodized aluminum plane sole:

  • Low center of gravity – ensures easily controlled planing.
  • Made from recyclable plastic.
  • High-quality anodized finish – Test stand: 7.5 km of planing distance without affecting the planing image.

Planing horns and hand guard

  • Ergonomically shaped – fits well in the hand.
  • No rust formation due to material properties – no discoloration of the wood.
  • Pleasantly light and can be used one-handed – ideal for quick planing on the construction site.

Anodized aluminum side parts

  • Available in various designs

Blade unit with replaceable blade

  • Adjustment of chip depth: Eccentric lever moves the entire blade unit – easy, fine, controlled.
  • Cutting angle 49°
  • Fast work without time-consuming sharpening
  • Easy blade change – quick access to spare replaceable blade, which is magnetically fixed in the replacement unit.
  • Blade unit is compactly held together by magnets even outside the plane body.

We measured for you:

  • Plane body length 240 mm
  • Plane body width 60 mm
  • Height to the top edge of the rear horn 115 mm
  • Weight 0.9 kg
  • Blade width 48 mm
Features
Plane body width60 mm
Designwithout engraving
Weight0.9 kg
Height to the top edge of the rear horn115 mm
Plane body length240 mm
Blade width48 mm
