9 Pcs Set Allen Keys short with short arm 1.5-2-2.5-3-4-5-6-8-10 mm ASAHI
Available, delivery time: 2-3 days
Product information
These Asahi angle keys have an extra short arm, allowing them to reach confined and especially height-restricted areas effectively. The short arm is only about half as long as a standard angle key. The arm length for each size is provided in the tables below.
Just like the standard angle keys from Asahi, these angle keys also have a screw-holding function at the end of their long arm (starting from size 3 mm). This consists of a ball catch, where the ball is pushed outward by a spring, securely holding the screw in place due to the resulting tension.
An additional, very useful feature is the fact that these angle keys are bent in a completely different way than conventional angle keys. In conventional angle keys, the short arm is bent at one of the six faces of the hexagon. In these Asahi angle keys, the short arm is bent not at a face, but at an edge. This increases the contact points at the screw head, allowing the screw to be turned even under conditions that would no longer permit the use of a conventional angle key.
Design with short long arm. 1.5 – 2.5 mm without screw-holding function due to technical reasons.
| Features | |
|---|---|
| Weight | 245 g |
| Size | 10 mm, 8, 6, 5, 4, 2, 1.5, 3, 2.5 |
| Manufacturer No. | DWS0910 |
| Scope of delivery | Delivered with a practical foldable plastic holder |
