Fence and Center Kit for
VERITAS Plunge Base
Available, delivery time: 2-3 days
Product information
VERITAS Edge Guide and Circle Routing Attachment
The edge guide and circle routing attachment allow you to use the edges of the workpiece as a guide when routing or to rout precise arcs and circles. The set consists of two straight guides made from thermally treated maple (both are 152 mm (6 inches) long, one is 38 mm (1-1/2 inches) wide, the other – for thin workpieces – is 16 mm (5/8 inches)), two curve guides, a circle routing attachment with three interchangeable tips (sharp needle, 6.35 mm (1/4 inch) pin, and flat disc), and two 152 mm (6 inches) long rods.
The 152 mm (6 inches) long rods allow for a distance from the guide to the cutter of zero to 114 mm (4-1/2 inches) with the straight guides and diameters of 19 mm (1/2 inch) to 444 mm (17-1/2 inches) with the circle routing attachment.
| Properties | |
|---|---|
| Width | 16 mm, 38 mm |
| Circle guide diameter range | 19 mm to 444 mm |
| Length | 152 mm |
| Material | thermally treated maple |
| Rod length | 152 mm |
